Cree XHP70.3 HI 45W 5157 Lumens SMD 7070 LED Emitter on 20 mm board

Bundle offers

Additional products

• Details
• Opinions

Details

Size	7 x 7 mm
Product Options	6 V 12 V  High-CRI
Maximum Drive Current	7200 mA (6 V) 3600 mA (12 V)
Max Power (W)	45 W
Max Light Output (lm)	5511 lm (HD) 5157 lm (HI)
Typical Forward Voltage	5.6 V White @ 2100 mA (6 V) 11.2 V @ 1050 mA (12 V)
Viewing Angle	120° (HD) 115° (HI)
Binning	85°C ANSI (White) 2- 3- and 5-Step EasyWhite®
Reflow Solderable	Yes JEDEC J-STD-020C-compatible
Thermal Resistance	0.9 °C/W
RoHS-Compliant	Yes
REACh-Compliant	Yes
